• Rating：0.1A 30VDC
• Contact Resistance：50mΩ Max.(Initial)
• Insulation Resistance：100MΩ Min (at 500 VDC)
• Dielectric Strength：AC 500V (50/60 Hz for 1 minute)
• Operating Force：150±100gf（Momentary)
250±100gf(Alternate)
200±100gf(Momentary With Click)
• Electrical Life：10.000 Cycles Min
• Ambient Temperature：-10℃ ~+ 80℃
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Electrical Life | Ambient Temperature | PDF下載 |
|---|---|---|---|---|---|---|---|---|
| R29091F□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
| R29093F□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
| R290901□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
| R29094F□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
| R29095F□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
| R29096F□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
| R290907□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
| R290902□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
| R290903□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
| R290904□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
| R290905□L | 0.1A 30VDC | 50mΩ Max.(Initial) | 100MΩ Min (at 500 VDC) | AC 500V (50/60 Hz for 1 minute) | 150±100gf（Momentary) 250±100gf(Alternate) 200±100gf(Momentary With Click) | 10.000 Cycles Min | -10℃ ~+ 80℃ | 暫無 |
