• Rating：DC 30V 0.1A
• Initial Contact Resistance：20mΩ Max
• Insulation Resistance：DC 500V 60 Sec.100MΩ Min.
• Dielectric Voltage：AC 500V(50~60HZ)60 Sec
• Tactile Travel：1.8mm
• Total Travel：3.6-4.0mm
• Work Travel：2.2±0.6mm
|
    |
| Part Number | Rating | Initial Contact Resistance | Insulation Resistance | Dielectric Voltage | Tactile Travel | Total Travel | Work Travel | Download |
|---|---|---|---|---|---|---|---|---|
| REPG150B02P | DC 30V 0.1A | 20mΩ Max | DC 500V 60 Sec.100MΩ Min. | AC 500V(50~60HZ)60 Sec | 1.8mm | 3.6-4.0mm | 2.2±0.6mm | NULL |
| REPG150Q30P | DC 30V 0.1A | 20mΩ Max | DC 500V 60 Sec.100MΩ Min. | AC 500V(50~60HZ)60 Sec | 1.8mm | 3.6-4.0mm | 2.2±0.6mm | NULL |
| REPG150R02P | DC 30V 0.1A | 20mΩ Max | DC 500V 60 Sec.100MΩ Min. | AC 500V(50~60HZ)60 Sec | 1.8mm | 3.6-4.0mm | 2.2±0.6mm | NULL |
| REPG150T02P | DC 30V 0.1A | 20mΩ Max | DC 500V 60 Sec.100MΩ Min. | AC 500V(50~60HZ)60 Sec | 1.8mm | 3.6-4.0mm | 2.2±0.6mm | NULL |
| REPG150W03P | DC 30V 0.1A | 20mΩ Max | DC 500V 60 Sec.100MΩ Min. | AC 500V(50~60HZ)60 Sec | 1.8mm | 3.6-4.0mm | 2.2±0.6mm | NULL |
| REPG150W05P | DC 30V 0.1A | 20mΩ Max | DC 500V 60 Sec.100MΩ Min. | AC 500V(50~60HZ)60 Sec | 1.8mm | 3.6-4.0mm | 2.2±0.6mm | NULL |
